1.5mm 60Mils Wastewater Treatment HDPE Geomembrane Sheet For Sewage Storage Tanks

Product Categories

HDPE Geogrid [4]
Polyester Geogrid [97]
Fiberglass Geogrid [57]
Uniaxial Geogrid [7]
Biaxial Geogrid [11]
Polypropylene Nonwoven Geotextile [36]
HDPE Geomembrane [74]
Triaxial Geogrid [4]
Composite Geogrid [17]
Plastic Geogrid [5]
Composited Membrane [9]
Polyester Nonwoven Geotextile [35]
Woven Geotextile [7]
Erosion Control Geocell [25]
Basalt Geogrid [4]
Waterproof Membrane [5]
Composite Drainage Net [3]

Shenzhou Earth Working Material Co. Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

1.5mm 60Mils Wastewater Treatment HDPE Geomembrane Sheet For Sewage Storage Tanks

Brand Name : SZ

Model Number : HDPE LDPE LLDPE

Certification : ISO

Place of Origin : CHINA

MOQ : 30000 square meters

Price : $0.3-$2.0/SQM

Payment Terms : T/T,L/C

Supply Ability : 100 Tons per day

Delivery Time : 5-8 days

Packaging Details : Packed in woven bag or your requirements

Product Name : HDPE Geomembrane Sheet

Thickness : 1.5mm 60mil

Application : Sewage storage tanks

Function : Wastewater Treatment

Material : HDPE LDPE LLDPE

Type : Smooth or Textured

Length : 50m-100m

Width : 1m-8m

Contact Now

1.5mm 60Mils Wastewater Treatment HDPE Geomembrane Sheet For Sewage Storage Tanks

Yixing Shenzhou Company Introduction

Yixing Shenzhou Factory was established in 2004, Designed and manufactured in-house at ISO 9001 certified manufacturing facilities our line to meets demanding QA/QC requirements and are continuously tested to rigorous ASTM standards both in-house and by leading independent geosynthetics.

• Product availability:

Plastic Geogrid ( Biaxial / Uniaxial / Triax / Hexagon )

Warp knitted Fiberglass geogrid coated with bitumen

Warp knitted woven coated polyester geogrid

HDPE Geocell

Non Woven Geotextile with PET and PP material. With staple fibre and filament process

HDPE / LDPE / LLDPE Geomembrane

Geocomposited Geogrid / Geocomposited membrane

GCL

Custimized product

1.5mm 60Mils Wastewater Treatment HDPE Geomembrane Sheet For Sewage Storage Tanks

ASTM Standard, GRI GM13 HDPE Geomembrane Specification:

Properties	Test method	GM075	GM100	GM125	GM150	GM200	GM250	GM300
Thickness	D5199	0.75mm	1.00mm	1.25mm	1.50mm	2.00mm	2.50mm	3.00mm
Density	D1505	0.940	0.940	0.940	0.940	0.940	0.940	0.940
Tensile properties 1. Yield strength 2. Breaks strength 3. Yield elongation 4. Break elongation	D6693 Type IV	11KN/m 20KN/m 12% 700%	15KN/m 27KN/m 12% 700%	18KN/m 33KN/m 12% 700%	22KN/m 40KN/m 12% 700%	29KN/m 53KN/m 12% 700%	37KN/m 67KN/m 12% 700%	44 KN/m 80 KN/m 12% 700%
Tear resistance	D1004	93N	152N	156N	187N	249N	311N	374N
Puncture resistance	D4833	240N	320N	400N	480N	640N	800N	960N
Stress crack resistance	D5397(App.)	300hr	300hr	300hr	300hr	300hr	300hr	300hr
Carbon black content	D1603	2.0%	2.0%	2.0%	2.0%	2.0%	2.0%	2.0%
Oxidative induction time (OIT)	D3895	100 min	100min	100min	100 min	100min	100min	100min

Comparison of Geomembrane Liners

Feature / Material	HDPE Geomembrane	PVC Liner	LDPE Geomembrane
Impermeability	Excellent (very low permeability)	Good, but slightly higher leakage	Good, but lower than HDPE
Chemical Resistance	Excellent (acids, alkalis, oils)	Moderate (not ideal for solvents)	Good, but less than HDPE
UV & Weather Resistance	Very strong (20–50 years lifespan)	Poor to moderate (needs covering)	Moderate (shorter service life)
Mechanical Strength	High tensile, tear, and puncture resistance	Flexible, but weaker strength	Lower tensile strength than HDPE
Flexibility	Rigid, less flexible	Very flexible, easy to install	Flexible, easier than HDPE
Durability / Lifespan	20–50 years	5–15 years	5–15 years
Environmental Safety	Non-toxic, eco-friendly	May release plasticizers over time	Generally safe, but less stable
Cost	Moderate (higher than PVC/LDPE, but long-term cost-saving)	Low initial cost	Moderate (between PVC and HDPE)
